Main features
Place Setting Capacity | 14 |
Energy Efficiency Class | D |
Water consumption (l) | 11.5 |
Noise Level (dB) | 48 |
Programme Control | Touch Button |
Time remaining display | No |
Number of Programmes | 6 |
Number of Wash Temperatures | 5 |
Anti Flood Devices | Overflow Safety |
Salt Indicator - Light | Yes |
Rinse Aid Indicator - Light | Yes |
Adjustable Rinse Aid Dosage | Yes |
Adjustable Water Softener | No |
Floor projected "Programme on" Led Spot | Yes |
Programmes
Programme 1 | Eco |
Programme 2 | Auto |
Programme 3 | Intensive |
Programme 4 | Quick&Shine |
Programme 5 | Mini |
Programme 6 | Prewash |
Quick Wash Duration (min) | 30 |
Eco Wash Duration (min) | 3:10 |
Dimensions & Weights
Product height (mm) | 818 |
Product width (mm) | 598 |
Product depth (mm) | 550 |
Carton height (mm) | 859 |
Carton width (mm) | 644 |
Carton depth (mm) | 661 |
Net Weight (kg) | 35.7 |
Gross Weight (kg) | 38.7 |
Product Fiche Information
Loading Capacity (Place Settings) | 14 |
Energy Efficiency Class | D |
Noise Level | 48 |
Energy consumption per 100 cycles (kWh/100 cycles) | 85 |
Energy consumption per cycle (Eco programme) (kWh) | 0.849 |
Water consumption per cycle (Eco programme) (L) | 11.5 |
Eco Programme duration (h:min) | 3:10 |
Noise Class | C |
Interior Configuration
Additional Cutlery Tray (removable) | No |
Cutlery Basket (removable) | Yes |
Folding Tines on Upper Basket to Place Saucepans/bowls | No |
Upper Basket Height Adjustment Type | Loaded adjustable (3 positions) |
Upper Basket Cup Racks | Adjustable |
Upper Basket Handle for easy grip | Yes |
Folding Tines on Lower Basket to Place Saucepans/bowls | 4 |
Lower Basket Handle for easy grip | Yes |
Maximum Plate Diameter in Lower Basket (cm) | 29.5 |
Maximum Plate Diameter in Upper Basket (cm) | 26 |
Functions
Half Load | Yes |
Tablet Function | Yes |
Child lock | No |
Time delay | 3-6-9h |
Function 1 | Tablet |
Function 2 | Half Load |
Connection & Installation
Needs only Cold Water Supply | Yes |
Water Pressure | 3-10 bar |
Voltage/Frequency | 220-240 V / 50 Hz |
Total Power (W) | 1800-2100 |
Heater Power (W) | 1800 W |
Furniture Door Weight Range (kg) (for BI) | 3.0 - 9.0 |
Door Balance/Hinge adjustment (for BI) | Self Adjusting |
Back Feet adjustable from front (for BI) | Yes |
Maximum Feet adjustment (cm) | 10 |
Model Codes
DIN16430 | EAN:8690842388620 |
